Sony VPL-FHZ65 User Manual

55
OUTPUT A MONITOR output terminal: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative, 75
ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75 ohms
terminated, Sync signal: HD, VD 4 V (open), 1 Vp-p (75
ohms), positive/negative
Audio output terminal: Stereo mini jack, stereo, 1
Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kilohms
OUTPUT B DVI-D output terminal: DVI-D 24-pin (Single link),
DVI 1.0 compliant, non-HDCP compliant
Control signal
input/output
RS-232C terminal: D-Sub 9 pin male
LAN terminal: RJ45, 10BASE-T/100BASE-TX
CONTROL S input terminal (DC power supply):
Stereo mini jack, 5 Vp-p, Plug in power DC 5 V
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/20% to 80% (no
condensation)
Storage
temperature/
Storage humidity
–10 °C to +60 °C (14 °F to +140 °F)/ 20% to 80% (no
condensation)
Power required VPL-FHZ65: AC 100 V to 240 V, 5.5 A to 2.3 A, 50/60
Hz
VPL-FHZ60: AC 100 V to 240 V, 4.5 A to 1.9 A, 50/60
Hz
Power
consumption
AC 100 V to
120 V
VPL-FHZ65: 509 W
VPL-FHZ60: 420 W
AC 220 V to
240 V
VPL-FHZ65: 492 W
VPL-FHZ60: 408 W
Power
consumption
(Standby Mode)
AC 100 V to
120 V
VPL-FHZ65: 0.5 W (when “Standby Mode” is set to
“Low”)
VPL-FHZ60: 0.5 W (when “Standby Mode” is set to
“Low”)
AC 220 V to
240 V
VPL-FHZ65: 0.5 W (when “Standby Mode” is set to
“Low”)
VPL-FHZ60: 0.5 W (when “Standby Mode” is set to
“Low”)
Item Description
Model name VPL-FHZ65/VPL-FHZ60

Sony VPL-FHZ65 Specifications

General

Matrix size	0.76 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	10000:1
Screen size compatibility	40 - 600 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	30 °
Focus	Auto
Throw ratio	1.39 - 2.23:1
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
3D	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
Serial interface type	RS-232C
USB 2.0 ports quantity	0
Noise level	28 dB
Placement	Desktop
Product type	Large venue projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	509 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Remote control type	Wired

Weight and Dimensions

Depth	515 mm
Width	460 mm
Height	169 mm
Weight	16000 g
