The Installation Menu
The Installation menu is used for installing the projector.
Setting items Description
Screen Fitting Adjusts the distortion of the projected image that occurs due to installation
conditions or when a portion of the image spreads beyond the screen.
*1
Warping: Select an adjustment point and move it vertically/horizontally to
adjust the image distortion.
V Keystone: Adjusts the vertical keystone distortion. The higher the
setting, the narrower the upper side of the projected image. The lower the
setting, the narrower the lower side of the projected image.
*2
H Keystone: Adjusts the horizontal keystone distortion. The higher the
setting, the shorter the right side of the projected image. The lower the
setting, the shorter the left side of the projected image.
*2
V Linearity: Adjusts the projected image so that the height of the upper
half and lower half will be the same. The higher the setting, the narrower
the upper half of the projected image. The lower the setting, the narrower
the lower half of the projected image.
H Linearity: Adjusts the projected image so that the width of the right half
and left half will be the same. The higher the setting, the narrower the right
half of the projected image. The lower the setting, the narrower the left half
of the projected image.
Reset: Resets all of the Screen Fitting items.
Multi Screen When composing one screen with multiple projections, you can overlap
portions of different projections or tile the projections.
Color Space Changes the color space. The same adjustments as in “Color Space”
(page 25) in the Picture menu are available.
Color
Matching
*3
Adjusts the overall brightness and hue of the projected image.
Adjust: Select one of 6 signal levels and adjust the brightness or hue.
Level 1 - 6: Select the brightness level to adjust.
Brightness: Adjusts the brightness of the selected brightness level.
Color: Adjusts the hue of the selected brightness level.
Reset: Resets all of the adjusted values.
Edge
Blending
Sets the settings regarding edge blending.
Reset: Resets all of the Blend Settings, Blend Fitting, and Zone Black
Level Adj. values.

Sony VPL-FHZ65 Specifications

General

Matrix size	0.76 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	10000:1
Screen size compatibility	40 - 600 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	30 °
Focus	Auto
Throw ratio	1.39 - 2.23:1
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
3D	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
Serial interface type	RS-232C
USB 2.0 ports quantity	0
Noise level	28 dB
Placement	Desktop
Product type	Large venue projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	509 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Remote control type	Wired

Weight and Dimensions

Depth	515 mm
Width	460 mm
Height	169 mm
Weight	16000 g
