Sony VPL-FHZ65 User Manual

59
HDMI terminal (HDMI, female)
Acceptable Input Signals
Computer signal
1 T.M.D.S.
Data2+
11 T.M.D.S.
Clock Shield
2 T.M.D.S.
Data2 Shield
12 T.M.D.S.
Clock–
3 T.M.D.S.
Data2–
13 NC
4 T.M.D.S.
Data1+
14 RESERVED
(N.C.)
5 T.M.D.S.
Data1 Shield
15 SCL
6 T.M.D.S.
Data1–
16 SDA
7 T.M.D.S.
Data0+
17 GND
8 T.M.D.S.
Data0 Shield
18 +5V Power
9 T.M.D.S.
Data0–
19 Hot Plug
Detect
10 T.M.D.S.
Clock+
Resolution
fH [kHz]/
fV [Hz]
Input terminal
INPUT A
INPUT B/
INPUT C/
INPUT D
640 × 350 31.5/70
z –
37.9/85
z –
640 × 400 31.5/70
z –
37.9/85
z –
640 × 480 31.5/60
zz
35.0/67 z –
37.9/73
z –
37.5/75
z –
43.3/85
z –
800 × 600 35.2/56 z –
37.9/60
zz
48.1/72 z –
46.9/75
z –
53.7/85
z –
832 × 624 49.7/75
z –
1024 × 768 48.4/60
zz
56.5/70 z –
60.0/75
z –
68.7/85
z –
1152 × 864 64.0/70
z –
67.5/75
z –
77.5/85
z –
1152 × 900 61.8/66
z –
1280 × 960 60.0/60
zz
75.0/75 z –
1280 × 1024 64.0/60
zz
80.0/75 z –
91.1/85
z –
1400 × 1050 65.3/60
zz
1600 × 1200 75.0/60 zz
1280 × 768 47.8/60 zz
1280 × 720 45.0/60 zz
*2
1920 × 1080 67.5/60 – z
*2
1366 × 768 47.7/60 zz
1440 × 900 55.9/60 zz
1680 × 1050 65.3/60 zz
1280 × 800 49.7/60 zz
1920 × 1200 74.0/60 z
*1
z
*1
1600 × 900 60.0/60 z
*1
z
*1
Resolution
fH [kHz]/
fV [Hz]
Input terminal
INPUT A
INPUT B/
INPUT C/
INPUT D

Sony VPL-FHZ65 Specifications

General

Matrix size	0.76 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	10000:1
Screen size compatibility	40 - 600 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	30 °
Focus	Auto
Throw ratio	1.39 - 2.23:1
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
3D	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
Serial interface type	RS-232C
USB 2.0 ports quantity	0
Noise level	28 dB
Placement	Desktop
Product type	Large venue projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	509 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Remote control type	Wired

Weight and Dimensions

Depth	515 mm
Width	460 mm
Height	169 mm
Weight	16000 g
