Sony WF-1000XM3 Series User Manual

WF-1000XM3
20
Sony CONFIDENTIAL
For Authorized Servicer
2-3. CASE INNER BLOCK
2 claw
5 claw
5 claw
1 Insert the jig into the space
and remove the two claws.
Note 1: When using a jig, please work
carefully so as not to damage
the case outer and lid.
3 Open the lid.
Turn around.
rear side
top side
7 Peel the adhesive sheet hall
off of the case outer.
8 case inner block
6 Lift up the case inner block
in the direction of the arrow.
case outer
2 claw
4 Insert the jig into the space
and remove the two claws.
Note 2: When using a jig, please work
carefully so as not to damage
the case outer and case inner.
case outer
case inner
case outer
lid
lid
7 Peel the adhesive sheet hall
off of the case outer.
guide line
guide line
3DVWLQJSRVLWLRQRIWKHDGKHVLYH
VKHHWKDOO
adhesive sheet hall
3DVWLQJSRVLWLRQRIWKHDGKHVLYH
VKHHWKDOO
adhesive sheet hall
guide line
guide line
front side
bottom side
bottom side
rear side
top side
front side
SYSSET
2020/04/0306:12:21(GMT+09:00)

Sony WF-1000XM3 Series Specifications

General

Type	True Wireless
Bluetooth Version	5.0
Driver Unit	6mm
Charging Time (Earbuds)	Approx. 1.5 hours
Charging Time (Charging Case)	Approx. 3.5 hours
Quick Charging	10 min charge for 90 min playback
Weight (Charging Case)	Approx. 77g
Touch Controls	Yes
Frequency Response	20 Hz - 20, 000 Hz (44.1 kHz Sampling)
Bluetooth Profiles	A2DP, AVRCP, HFP, HSP
Audio Codec	SBC, AAC
Water Resistance	No
NFC	Yes
Microphone	Yes
Compatibility	Android, iOS
Noise Cancellation	Active Noise Cancellation
Battery Life (Earbuds)	Up to 6 hours
Battery Life (Charging Case)	Up to 24 hours (with ANC on), up to 32 hours (with ANC off)
Weight (Earbuds)	Approx. 8.5g each
Voice Assistant Support	Google Assistant, Amazon Alexa
Wireless Range	30 ft (10 m)
