STIEBEL ELTRON DHE Connect 18 User Manual

ENGLISH
www.stiebel-eltron.com DHEConnect | DHETouch | 81
INSTALLATION
Preparation
Central thermostatic valve (ZTA 3/4)
Use the thermostatic valve for central premixing when, for exam-
ple, operating an instantaneous water heater with a solar thermal
system.
9. Preparation
9.1 Installation location
!
Material losses
Install the appliance in a room free from the risk of frost.
 Always install the appliance vertically and near the draw-off
point.
The appliance is suitable for undersink and oversink installation.
Undersink installation
D0000056242
1
2
1 Cold water inlet
2 DHW outlet
Oversink installation
D0000057030
12
1 Cold water inlet
2 DHW outlet
Note
 Mount the appliance on the wall. The wall must have
sufficient load bearing capacity.
