WORKSHOP MANUAL
EDITION
PAGE
4 /
124
They are used to draw the attention of the operator, reminding him to perform the interventions
with the necessary attention and caution.
Indicates operations that should be carried out with utmost care to avoid impairing the func-
tionality and safety of the machine.
Indicates operations that should be carried out with utmost care to avoid injury to operators.
▶▶ Highlights all those operations that require different working methods depending on the type
of machine, subsequent modifications and accessories fitted.
Indicates the cross-reference to other parts of the manual, followed by the number of the rel-
evant chapter, paragraph or sub-paragraph.
Some paragraphs are preceded by a definition that highlights their importance:
General reference for the correct maintenance execution and methods.
Specific procedures or information necessary to avoid damage to the machine or
equipment.
Non-observance will result in the risk of injury to oneself or others.
Non-observance will result in the risk of serious injury or death to oneself or
others.
Whenever reference is made to a position on the machine “front”,
“back”, “left” or “right” side, this refers to the positions of the seat-
ed operator.
The following abbreviations are used in this manual
Rh / Lh = Right / Left
Min / Max = Minimum / Maximum
Chap. = Chapter
Par. = Paragraph
HST = Hydrostatic Transmission
PTO = Power Take-Off
