WORKSHOP MANUAL
EDITION
PAGE
74 /
124
1. Lift the front part and stabilize the machine
.
2. Remove the front wheels
from 1 to
4.
3. Place a container under the rear transmission
unit and drain all the oil by unscrewing the filter
cap (1).
Unscrew the two drain plugs (2) and (3).
4. Place a container under the front transmission
unit and drain all the oil by unscrewing the two
caps (4) and (5).
5. Disconnect all mechanical connections:
– release the terminal (6) of the brake cable;
– release the spring (7) of the PTO engage-
ment tightener;
– unscrew the nut (8) and remove the support
(9) of the by-pass control rod (10).
