FSA 90 R
English
17
Power supply (mains) voltage and
operating voltage must be the same.
N Insert the plug (1) in the wall
outlet (2).
A self test is performed after the charger
is connected to the power supply. During
this process, the light emitting diode (1)
on the charger lights up green for about
1 second, then red and goes off again.
When delivered, the battery is not fully
charged.
It is advisable to charge the battery
completely before using it for the first
time.
N Connect the charger to the power
supply – mains voltage and
operating voltage of the charger
must be the same – see
"Connecting Charger to Power
Supply".
Operate the charger only in a closed, dry
space at ambient temperatures between
41 °F (5 ° C) and 104 °F (40 °C).
Only charge dry batteries. Allow a damp
battery to dry before charging.
N Slide the battery (1) into the
charger (2) until you start to feel
resistance – then push it in until it
engages.
The LED (3) on the charger comes on
when the battery is inserted – see "LED
on Charger"
Charging begins as soon as the
LEDs (4) on the battery glow green –
see "LEDs on Battery".
Charge time depends on a number of
factors, including battery condition,
ambient temperature, etc., and may
therefore vary from the times specified.
The battery heats up during operation in
the power tool. If a hot battery is inserted
in the charger, it may be necessary to
cool it down before charging. The
charging process begins only after the
battery has cooled down. The time
required for cooling may prolong the
charge time.
The battery and charger heat up during
the charging process.
AL 300, AL 500 Chargers
The AL 300 and AL 500 chargers are
equipped with a battery cooling fan,
which can be heard during operation.
Connecting Charger to
Power Supply
Charging the Battery
