Stihl FSA 90 R User Manual

FSA 90 R
English
28
Definitions
1. Drive Tube
Encloses and protects the cables
between the motor and control
handle.
2. Loop Handle
For easy control of machine during
cutting work.
3. Trigger Switch
Switches the motor on and off and
controls the speed of the motor.
4. Set Wheel
Limits the maximum position of the
trigger switch.
5. Retaining Latch
Locks or unlocks the trigger switch.
6. Trigger Switch Lockout
Must be depressed before the
trigger switch can be activated.
7. Control Handle
The handle of the trimmer held by
the rear hand.
8. Battery Compartment
Accommodates the battery in the
unit.
9. Mowing Head
The cutting attachment for cutting
grass and similar material.
10. Line Limiting Blade
Metal blade on the deflector which
keeps the line of the mowing head
at the proper length.
11. Deflector
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the cutting attachment and from
contact with the cutting attachment.
12. Battery Locking Tabs
Secure the battery in the unit.
13. Battery
Supplies the motor with electrical
power.
14. Light Emitting Diodes (LED) on
Battery
Indicate the state of charge and
operating condition of the battery.
15. Push Button
For activating light emitting diodes
(LED) on battery.
16. Charger
Charges the battery.
17. Light Emitting Diode (LED) on
Charger
Indicates charger operating mode
and certain problems.
18. Power Supply Cord
Supplies electric current to charger.
Battery
The machine may be operated only with
original STIHL AP and AR rechargeable
batteries.
Power tool running time is dependent on
the energy content of the battery.
STIHL AP series rechargeable batteries
may be charged only with original
STIHL AL series chargers.
Charger
Specifications
Type: Lithium-ion
Designation: AP, AR
AL 100
Power supply: 120 V / 60 Hz
Rated current: 1.3 A
Power consumption: 75 W
Charge current: 1.6 A
Insulation: II, E (double
insulated)
AL 300
Power supply: 120 V / 60 Hz
Rated current: 4.7 A
Power consumption: 330 W
Charge current: 6.5 A
Insulation: II, E (double
insulated)

Stihl FSA 90 R Specifications

General

Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Product color	Black, Orange, White
Vibration emission	4.8 m/s²
Sound pressure level	73 dB
Cutting diameter (max)	380 mm
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Length	1770 mm
Weight	2800 g
