Stihl GHE 355 User Manual

EN
13
0478 201 8314 C - EN
6. Standard equipment
Item Designation Qty.
A Basic unit with lower chute 1
B Upper chute 1
C Wheel axle 1
D Wheel carrier 1
E Wheel lock 2
F Bolt, M6 x 55 2
G Hexagon nut 2
H Wheel 2
I Wheel cap 2
J Wheel plug 2
K Roll pin 2
L Self-tapping screw P6 x 50 2
M Discharge flap 1
N Ejection chute extension 1
O Strip 1
P Pin 2
Q Torx screw P5 x 20 3
R Torx screw P5 x 10 2
S Safety screw 3
T Cable clip 1
U Installation tool 1
x Instruction manual 1
Item Designation Qty.

Stihl GHE 355 Specifications

General

Power	2500 W
Product color	Black, Orange, White
Uncertainty K	2.4 dB
Cutting system	Blade
AC input voltage	230 V
Transport wheels	Yes
Rated speed (max)	2750 RPM
Sound power level	100 dB
Material throughput	- kg/h
Sound pressure level	94 dB
Collection box capacity	- L
Maximum branch thickness	35 mm

Weight and Dimensions

Weight	30000 g
