Stihl GHE 355 User Manual

0478 201 8314 C - EN
14
7.1 Attaching the wheel axle and
wheels
● Attach wheel axle (C) to wheel
carrier (D) with wheel locks (E),
bolts (F) and hexagon nuts (G) and
tighten using assembly tool (U)
(4 - 6Nm).
● Push wheel (H) onto the mounted
wheel axle.
● Push in wheel plug (J) and secure by
driving in roll pin (K).
● Fit wheel cap (I).
● Repeat this procedure on the other
side.
7.2 Installing the chassis and ejection
chute
1 Install the ejection chute extension
● Place basic unit (A) onto a block of
wood with a height of approx. 15-
20 cm.
● Engage hooks (1) of ejection chute
extension (N) into openings (2) on the
rear of basic unit (A) and turn the
extension downwards so that the front
part of the basic unit is precisely
inserted in the opening of the ejection
chute extension.
● Fasten screws (R) in the lugs of
hooks (1) (1 - 2Nm).
2 Attach the chassis
● Push the chassis with both wheel
carriers (3) as far as they will go into the
guides on basic unit (4).
7. Preparing the machine for
operation
Avoid damage to the machine.
Strictly observe all tightening
torques in the following section
"Preparing the machine for
operation" to avoid damaging the
machine.

Stihl GHE 355 Specifications

General

Power	2500 W
Product color	Black, Orange, White
Uncertainty K	2.4 dB
Cutting system	Blade
AC input voltage	230 V
Transport wheels	Yes
Rated speed (max)	2750 RPM
Sound power level	100 dB
Material throughput	- kg/h
Sound pressure level	94 dB
Collection box capacity	- L
Maximum branch thickness	35 mm

Weight and Dimensions

Weight	30000 g
