HL 95, HL 95 K, HL 100, HL 100 K
English
27
STIHL single cylinder four-stroke engine
with mixture lubrication
HL 95, HL 95 K
HL 100, HL 100 K
Ignition System
Electronic magneto ignition
Starter rope
Fuel System
Weight
Dry weight with 135° adjustable cutter
bar
Cutting blades
Noise and Vibration Data
Noise and vibration data are measured
at idling and maximum rated speed in a
ratio of 1:4.
For further details on compliance with
Vibration Directive 2002/44/EEC see
www.stihl.com/vib/
Sound pressure level L
p
to ISO 11201
Sound pressure level L
p
to ISO 10517
Sound power level L
w
to ISO 3744
Sound power level L
w
to ISO 10517
Vibration measurement a
hv,eq
to
ISO 10517
Specifications
Displacement: 28.4 cc
Bore: 38 mm
Stroke: 25 mm
Engine power to
ISO 8893: 0.95 kW (1.3 bhp)
Rated speed to
ISO 8893: 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed: 9,500 rpm
Valve clearance,
inlet: 0.10 mm
Valve clearance,
exhaust: 0.10 mm
Displacement: 31.4 cc
Bore: 40 mm
Stroke: 25 mm
Engine power to
ISO 8893: 1.05 kW (1.4 bhp)
Rated speed to
ISO 8893: 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed: 9,500 rpm
Valve clearance,
inlet: 0.10 mm
Valve clearance,
exhaust: 0.10 mm
Spark plug (resistor
type): Bosch USR 7AC
Electrode gap: 0.5 mm
Diameter: 3.0 mm
Length: 850 mm
Fuel tank capacity: 530 cc (0.53 l)
HL 95, HL 100: 6.9 kg
HL 95 K, HL 100 K: 6.4 kg
Type: Double-edged for
bidirectional
cutting
Cutting length: 500 mm
Tooth spacing: 35 mm
Tooth height: 20 mm
Sharpening angle: 45° to horizontal
HL 95: 89 dB(A)
HL 95 K: 88 dB(A)
HL 100: 88 dB(A)
HL100K: 88dB(A)
HL 95: 102 dB(A)
HL 95 K: 102 dB(A)
HL 100: 101 dB(A)
HL 100 K: 102 dB(A)
Left handle:
HL 95: 5.2 m/s
2
HL 95 K: 5.3 m/s
2
Right handle:
HL 95: 5.0 m/s
2
HL 95 K: 5.0 m/s
2
