HL-KM
français
36
1 Couteaux
2 Réducteur (engrenage de
commande des couteaux)
3 Tube
4 Réducteur (engrenage d'angle)
5 Douille coulissante
6 Secteur d'encliquetage
7 Levier de réglage
8 Protège-couteaux
9 Douille
Principales pièces
2
8
4
1
5
7
4
3
2
475BA008 KN
6
3
