Stihl HSE 61 User Manual

45HSE 61, HSE 71, HSE 81
: Release the slide (1) and allow it
to engage in the quadrant.
: Pull the blue wire (1) forward to
take up slack and push it into the
retaining slots.
: Pull the black wire (2) forward to
take up slack and push it into the
retaining slot.
– Close the housing, b 6.2.
1
1
2

Stihl HSE 61 Specifications

General

Blade size	500 mm
Blade type	Double blade
Product color	Orange, Black, Grey
Vibration emission	5.3 m/s²
Engine power	500 W
Power source	AC
AC input voltage	230 - 240 V
Power cable length	0.31 m

Weight and Dimensions

Depth	1130 mm
Weight	3900 g
