Stihl MS 181 Instruction Manual

MS 171, MS 171 C, MS 181, MS 181 C, MS 211, MS 211 C
English
24
Preparing the machine
N Before fueling, clean the cap and
the area around it to ensure that no
dirt falls into the fuel tank
N Always position the machine so that
the cap is facing upwards
Tank cap markings
Tank caps and fuel tanks may be
marked in different ways
Depending on the version, your machine
may be equipped with a tank cap and
fuel tank with or without symbols.
Tank cap without symbols
Opening
N Swing the grip to the upright
position.
N Rotate the tank cap about a quarter
turn counterclockwise.
N Remove the cap.
Filling up with fuel
Take care not to spill fuel while fueling
and do not overfill the tank.
STIHL recommends you use the STIHL
filler nozzle for fuel (special accessory).
N Fill up with fuel.
Closing
Grip must be vertical:
N Fit the cap – positioning marks on
tank cap and filler neck must be in
alignment.
N Press the cap down as far as stop.
Fueling
001BA229 KN
Left: Tank cap without symbols
Right: Tank cap with markings and
symbols on cap and tank
001BA240 KN
001BA218 KN
001BA219 KN
001BA224 KN
001BA220 KN

Stihl MS 181 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	400 mm
Product color	Black, Grey, Orange
Chain tensioner	Yes
Motor speed (max)	10000 RPM
Fuel tank capacity	0.266 L
Engine displacement	31.8 cm³
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.5 m/s²
Sound pressure level	100 dB

Weight and Dimensions

Weight	43004300 g
