Stihl MS 181 Instruction Manual

MS 171, MS 171 C, MS 181, MS 181 C, MS 211, MS 211 C
English
37
If there is a noticeable loss of engine
power
N Remove the shroud – see "Shroud".
N Always replace damaged filters.
N Clean away loose dirt from around
the filter.
N Push the two locking tabs upwards,
tilt the air filter towards the rear
handle and remove.
NOTICE
To avoid damaging the filter, do not use
tools for removing and installing the air
filter.
N Blow out the filter with compressed
air from the clean air side.
If the filter fabric is caked with dirt or no
compressed air is available:
N Wash the filter in a clean, non-
flammable solution (e.g. warm
soapy water) and then dry.
N Reinstall the air filter.
N Install the shroud – see "Shroud".
General Information
The carburetor comes from the factory
with a standard setting.
This setting provides an optimum fuel-air
mixture under most operating
conditions.
Preparations
N Shut off the engine.
N Check the air filter and clean or
replace if necessary.
N Check the spark arresting screen
(not in all models, country-specific)
in the muffler and clean or replace if
necessary.
Standard Setting
N Turn high speed screw (H)
counterclockwise as far as stop (no
more than 3/4 turn).
N Turn the low speed screw (L)
clockwise as far as stop, then turn it
back 1/4 turn.
Adjusting Idle Speed
N Carry out the standard setting.
N Start and warm up the engine.
Engine stops while idling
N Turn the idle speed screw (LA)
clockwise until the chain begins to
run – then back it off 2 turns.
Saw chain runs while engine is idling
N Turn the idle speed screw (LA)
counterclockwise until the chain
stops moving – then turn it another
2 turns in the same direction.
WARNING
If the chain continues moving when the
engine is idling, have your saw checked
and repaired by your servicing dealer.
Erratic idling behavior, poor acceleration
(even though standard setting of low
speed screw is correct)
Idle setting is too lean
N Turn the low speed screw (L)
carefully counterclockwise, no
further than stop, until the engine
runs smoothly and accelerates well.
Cleaning the Air Filter
533BA009 KN
Adjusting the Carburetor
H
L
533BA020 KN
LA
L
533BA021 KN

Stihl MS 181 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	400 mm
Product color	Black, Grey, Orange
Chain tensioner	Yes
Motor speed (max)	10000 RPM
Fuel tank capacity	0.266 L
Engine displacement	31.8 cm³
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.5 m/s²
Sound pressure level	100 dB

Weight and Dimensions

Weight	43004300 g
