Stihl MS 181 Instruction Manual

MS 171, MS 171 C, MS 181, MS 181 C, MS 211, MS 211 C
English
52
ANDREAS STIHL AG & Co. KG
Badstr. 115
D-71336 Waiblingen
hereby confirms that
conform to the specifications of
Directives 2006/42/EC, 2004/108/EC
and 2000/14/EC and have been
developed and built in compliance with
the versions of the following standards
valid at the time of the production date:
EN ISO 11681-1, EN 55012,
EN 61000-6-1
The measured and guaranteed
equivalent sound power level has been
determined in accordance with Directive
2000/14/EC, Annex V, and standard
ISO 9207.
Measured sound power level
Guaranteed sound power level
The EC type approval test was carried
out at the
DPLF
Deutsche Prüf- und Zertifizierungsstelle
für Land- und Forsttechnik (NB 0363)
Spremberger Straße 1
D-64823 Groß-Umstadt
The technical documentation has been
retained by:
ANDREAS STIHL AG & Co. KG
Product approval
The year of construction and the serial
number are shown on the machine.
Waiblingen, 15.08.2014
ANDREAS STIHL AG & Co. KG
pp.
Thomas Elsner
Head of Product Group Management
EC Declaration of Conformity
Model: Chain saw
Make: STIHL
Type: MS 171
MS 171 C
MS 171 C-BE
MS 181
MS 181 C
MS 181 C-BE
MS 211
MS 211 C
MS 211 C-BE
Serial identification
number: 1139
Displacement
all MS 171: 31.8 cm
3
all MS 181: 31.8 cm
3
all MS 211: 35.2 cm
3
all MS 171: 112 dB(A)
all MS 181: 112 dB(A)
all MS 211: 113 dB(A)
all MS 171: 114 dB(A)
all MS 181: 114 dB(A)
all MS 211: 115 dB(A)
Certification No.:
all MS 171: K-EG-2009/4442
all MS 181: K-EG-2009/4446
all MS 211: K-EG-2009/4444

Stihl MS 181 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	400 mm
Product color	Black, Grey, Orange
Chain tensioner	Yes
Motor speed (max)	10000 RPM
Fuel tank capacity	0.266 L
Engine displacement	31.8 cm³
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.5 m/s²
Sound pressure level	100 dB

Weight and Dimensions

Weight	43004300 g
