60 MS 192 T
The handle housing and engine
housing are connected by vibration
damping rubber buffers and a
spring.
Damaged rubber buffers (annular
buffers) and springs must be
replaced.
The rubber buffer is located
between handle housing and
engine housing to secure the
handle housing without transmitting
vibrations.
Remove the carburetor box cover,
b 14.1
Remove the sprocket cover and bar
and chain, b 5.1
: Remove the screw (arrow).
217RA182 TG
: Take out the screws (arrows).
– Remove the rubber buffer.
217RA183 TG
: Examine the rubber buffer and
replace it if necessary.
– Reassemble parts in reverse
order.
– Tightening torques, b 3.5
217RA309 TG
11. Repairing the AV System 11.1 Annular Buffer
