RB 800
English
24
Definitions
1 Spray gun
Controls the high-pressure jet.
2 Coupling for high-pressure hose
To connect the high-pressure hose
to the spray gun.
3 Spray gun trigger
Opens and closes the valve in the
spray gun.
4 Trigger lockout
Blocks the Spray gun trigger.
5 Coupling for spray lance
To connect the spray lance to the
spray gun.
6 Spray lance
Directs the water from the spray gun
to the high-pressure nozzle
7 Coupling for high-pressure nozzle
To connect the high-pressure
nozzle to the spray lance.
8 High-pressure nozzle
Creates the form and intensity of the
high-pressure jet.
9 Pushbar
To push the pressure washer.
10 Holder for spray attachment
To store the spray attachment.
11 High-pressure hose
Transports the water from the high-
pressure pump to the spray gun.
12 Star knob
To release and fold down the
pushbar.
13 Coupling on high-pressure hose
To connect the high-pressure hose
to the spray gun and to the high-
pressure pump.
14 Coupling for high-pressure hose
To connect the high-pressure hose
to the high-pressure pump.
15 Suction hose for detergent
To draw off detergent from a
separate container.
16 Connector for water inlet with
screen
To connect the water hose to the
high-pressure pump. The screen
helps prevent dirt and debris from
entering the pump.
17 High-pressure pump oil sight glass
To check the fill level of pump oil in
the high-pressure pump.
18 Pressure/quantity control knob
To set the water pressure and water
quantity in the high-pressure pump.
19 Holder for high-pressure nozzles
To store the high-pressure nozzles.
20 Holder for high-pressure hose
To store the high-pressure hose.
21 High-pressure pump oil filler cap
To fill up the pump oil.
22 High-pressure pump oil drain plug
To drain the pump oil.
23 On/Off Switch
To start/stop the engine.
Engine
See engine instruction manual for
additional specifications.
High-pressure pump
Specifications
Manufacturer: Kohler
Model designation: CH 440
Type: Single cylinder
four-stroke
engine
Fuel: Gasoline
Rated / Permissible
Pressure:
psi 150-
4200
MPa 1-29
bar 10-290
Maximum water
throughput: gpm 4
l/min 15.1
l/h 910
Maximum suction height
from a tank: ft. 2
m0.6
Maximum kickback force N 60.6
Oil specification: SAE 15W-40
Oil fill quantity: oz. 13.35
ml 395
