Stihl RMA 2 RV User Manual

0478-131-9950-A
47
English 8 Removing and Fitting the Battery
8.1 Fitting the Battery
RMA 2 RPV:
The RMA 2 RPV lawn mower can be operated with two
batteries. As soon as the battery in the first battery
compartment (3) is discharged, the machine automatically
switches to the battery in the second battery
compartment (4). There must always be a battery in the first
battery compartment (3) when working.
RMA 2 RV:
The RMA 2 RV lawn mower is equipped with a battery
compartment (3) and a transport compartment (4). The lawn
mower can only be operated with the battery in battery
compartment (3). A replacement battery can be carried in
transport compartment (4).
► Open flap (1) as far as the stop and hold.
► Push battery (2) into battery compartment (3) as far as it
will go.
Battery (2) engages with a click and is locked in place.
► If a second battery is to be carried: fit the battery in battery
compartment (4) or transport compartment (4).
The battery engages with a click and is locked in place.
► Close flap (1).
8.2 Removing the Battery
► Place the lawn mower on a level surface.
► Open flap (1) as far as the stop and hold.
► Press locking lever (2).
The battery (3) is released.
► Remove battery (3).
► Close flap (1).
8 Removing and Fitting the Battery

Stihl RMA 2 RV Specifications

General

Type	Walk behind lawn mower
Cutting width	460 mm
Grass catcher	-
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	510 m²
Sound power level	88 dB
Handle(s) features	Adjustable, Ergonomic, Foldable, Soft grip
Standard deviation	2 dB
Vibration emission	1.4 m/s²
Sound pressure level	86 dB
Front wheels diameter	200 mm
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1420 mm
Width	500 mm
Height	1060 mm
Weight	23000 g
