Stihl RMA 2 RV User Manual

0478-131-9950-A
59
English 20 Specifications
20.1 STIHL RMA 2.2 RPV, RMA 2.2 RV Lawn
Mower
– Permissible battery: STIHL AP
– Weight without battery:
– RMA2.2RPV: 22.6kg
– RMA 2.2 RV: 22.4 kg
– Cutting width: 46 cm
– Speed: 3,150 rpm
– Speed in ECO mode: 2,800 rpm
– Minimum driving speed: 2.0 km/h
– Maximum driving speed (depending on the battery used):
– AP 100: 3.0 km/h
– AP 200: 3.7 km/h
– AP 300: 4.5 km/h
For information on the battery life see
www.stihl.com/battery-life.
20.2 Blade
– Minimum thickness a: 2 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°
20.3 STIHL AP battery
– Battery Technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation and storage:
-10°C to +50°C
20.4 Sound Values and Vibration Values
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 2.4 dB(A). The K value for
the vibration values is 0.7 m/s².
– Sound pressure level L
pA
measured in accordance with
EN 60335-2-77: 74 dB(A)
– Sound power level L
wA
measured in accordance with
2000/14/EC: 86 dB(A)
– Vibration value a
hv
measured in accordance with EN
60335-2-77, handlebar: 1.4 m/s²
The indicated vibration values have been measured in
accordance with a standardised test method and can be
used for the purpose of comparing electrical appliances. The
actual vibration values that occur may deviate from the
indicated values, depending on the type of application. The
indicated vibration values can be used for an initial
assessment of the vibration load. The actual vibration load
must be assessed. Times during which the electrical
appliance is switched off, along with times in which it is
switched on but running without load, can also be taken into
consideration.
For information on compliance with Employers' Vibration
Directive 2002/44/EC see www.stihl.com/vib.
20 Specifications

Stihl RMA 2 RV Specifications

General

Type	Walk behind lawn mower
Cutting width	460 mm
Grass catcher	-
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	510 m²
Sound power level	88 dB
Handle(s) features	Adjustable, Ergonomic, Foldable, Soft grip
Standard deviation	2 dB
Vibration emission	1.4 m/s²
Sound pressure level	86 dB
Front wheels diameter	200 mm
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1420 mm
Width	500 mm
Height	1060 mm
Weight	23000 g
