Stihl RMA 2 RV User Manual

0478-131-9950-A
56
English 19 Troubleshooting
19.1 Remedying Lawn Mower or Battery Faults
19 Troubleshooting
Fault LEDs on the
battery
Cause Remedy
The lawn mower
does not start when
switched on.
1 LED flashes
green.
The battery charge state is
too low.
► Charge the battery.
1 LED illuminates
red.
The battery is too warm or
too cold.
► Pull out the activation key.
► Remove the battery.
► Allow the battery to cool down or warm up.
3 LEDs flash red. There is a fault in the lawn
mower.
► Pull out the activation key.
► Remove the battery.
► Clean the electric contacts in the battery
compartment.
► Fit the battery.
► Switch the lawn mower on.
► If 3 LEDs still flash red: do not use the lawn mower
and consult a STIHL specialist dealer.
3 LEDs illuminate
red.
The lawn mower is too
warm.
► Pull out the activation key.
► Remove the battery.
► Allow the lawn mower to cool down.
4 LEDs flash red. There is a fault in the
battery.
► Remove the battery and fit it again.
► Switch the lawn mower on.
► If 4 LEDs still flash red: do not use the battery and
consult a STIHL specialist dealer.
The electrical connection
between the lawn mower
and battery has been
interrupted.
► Pull out the activation key.
► Remove the battery.
► Clean the electric contacts in the battery
compartment.
► Insert the activation key.
► Fit the battery.

Stihl RMA 2 RV Specifications

General

Type	Walk behind lawn mower
Cutting width	460 mm
Grass catcher	-
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	510 m²
Sound power level	88 dB
Handle(s) features	Adjustable, Ergonomic, Foldable, Soft grip
Standard deviation	2 dB
Vibration emission	1.4 m/s²
Sound pressure level	86 dB
Front wheels diameter	200 mm
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1420 mm
Width	500 mm
Height	1060 mm
Weight	23000 g
