Stihl SG 51 User Manual

SG 51, SG 71
English
17
6. Spray Wand.
Feeds spray solution to the nozzle.
7. Adjustable brass nozzle.
Adjustable from conical to full jet
spray pattern.
8. Cap.
Closes the spray solution container.
9. Gasket.
Seals the container.
10. Strainer.
Helps prevent impurities entering
the container.
11. Container.
Contains the spray solution.
12. Hand Lever.
Pump lever for producing spray
pressure.
13. Grip.
Operates the hand lever.
14. Pump barrel.
Houses pressure pump for
generating pressure.
15. Piston cup seal.
Seals the pump barrel.
16. Retaining pin.
Secures the lever to the shaft.
Specifications
SG 51
SG 71
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers.
Warranty claims following repairs can be
accepted only if the repair has been
performed by an authorized STIHL
servicing dealer using genuine STIHL
replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
Specifications
Operating pressure,
max.: 6 bar (87 PSI)
Flow volume, max.: 1.4 l/min
(85.43 cu.in/min)
Solution capacity,
max.:
12 l
(3.17 US gals)
Operating tempera-
ture, max.: 40°C (104°F)
Residual solution in
container: <0.25 l (8.5 fl.oz)
Recoil force: <20 N (4.5 lbf)
Dry weight: 4.5 kg (9.9 lbs)
Operating pressure,
max.: 6 bar (87 PSI)
Flow volume, max.: 1.4 l/min
(85.43 cu.in/min)
Solution capacity,
max.:
18 l
(4.76 US gals)
Operating tempera-
ture, max.: 40°C (104°F)
Residual solution in
container: <0.27 l (9.1 fl.oz)
Recoil force: <20 N (4.5 lbf)
Dry weight: 4.8 kg (10.6 lbs)
Maintenance and Repairs

Stihl SG 51 Specifications

General

Volume	12 L
Material	-
Product color	Black, Orange, White
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	4500 g
