Subaru 2006 Impreza - Illustrated Index; Exterior

To Next Page

To Previous Page

Illustrated index

Exterior

1 2 3

4 5

12 11 10 9 8

7 6

000168

1) Engine hood (page 11-4)

2) Headlight switch (page 3-22)

3) Replacing bulbs (page 11-44)

4) Wiper switch (page 3-27)

5) Moonroof (page 2-24)

6) Door locks (page 2-4)

7) Tire pressure (page 11-30)

8) Flat tires (page 9-4)

9) Tire chains (page 8-11)

10) Front fog light button (page 3-26)

11) Tie-down hooks (page 9-11)

12) Towing hooks (page 9-11)
