Subaru 2006 Impreza - Interior; Passenger Compartment Area

To Next Page

To Previous Page

Interior

Passenger compartment area

1 2 3

456

000186

1) Lower anchorages for child restraint

system (page 1-30)

2) Seatbelt (page 1-9)

3) Moonroof (page 2-24)

4) Parking brake lever (page 7-25)

5) Front seat (page 1-2)

6) Rear seat (page 1-6)
