Subaru EH72-2D Service Information

-.6.-
22) CARBURETOR
Set.gasket.onto.intake.manifold.and.install.
carburetor
M6.Flange.nut.:.4pcs
23) CHOKE CONTROL
Attach.chock.control.link.between.carburetor.
chock.lever.and.chock.control.lever
Attach.governor.spring.between.governor.
lever.and.speed.control.lever
3-4 REASSEMBLY PROCEDURES (DIFFERENCE)
#2 CYLINDER SIDE
SPARK PLUG CAP
GROMMT (PLUG CAP)
#2 CYLINDER SIDE ONLY
GASKET
(CARBURETOR)
CARBURETOR
GASKET
(ADAPTER)
CLEANER
ADAPTER
CHOKE
CONTROL ROD
RETURN
SPRING
LINK PIVOT
CHOKE
CONTROL
LINK
CHOKE
KNOB
CLAMP
M5 TAPPING
SCREW
Tightening torque
166.-.186.N•m
(170.-.190.kgf•cm)
(123.-.137.ft•lb)
The marking down wards.
GASKET (ADAPTER) GASKET (CARBURETOR)
