Subaru EX35 - 5-3 DISASSEMBLY PROCEDURE

- 13 -
5-3 DISASSEMBLY PROCEDURE
Step Parts to remove Remarks and procedures Fasteners
1
Drain the engine oill Remove a drain plug (M14 x 12mm) located on both
sides of the case.
Take care not to lose the gaskets.
*
To discharge oil quickly, remove the oil guage(M22).
14 mm spanner
2
Drain the fuel Shut (OFF) the fuel strainer.
Drain fuel from the carburetor drain.
+ or - screwdriver
Fig.5-3
GASKET
GASKET
OIL GAUGE
DRAIN PLUG
FUEL STRAINER
OFF
STEP 1
STEP 2
Fig.5-2
