BEFORE DRIVING

66J21-03E

52D249

NOTE:

The word “CENTER” is molded into the

buckle for the rear seat center belt. The

buckles are designed so a latch plate can

not be inserted into the wrong buckle.

60A039

To unfasten the belt, push the red

“PRESS” button on the buckle and allow

the belt to retract.

Seat Belt Reminder

Driver’s seat belt reminder light

66J019

Front passenger’s seat belt reminder

light

66J020

EXAMPLE
