3-12 MOTOR INSTALLATION
DF60/70 DUAL MOTOR
AMinimum
1 397 mm
EMinimum
121 mm
55 inch 4.8 inch
BMinimum
559 mm
F Maximum
219 mm
22 inch 8.6 inch
CMinimum
200 mm
G Maximum
219 mm
7.9 inch 8.6 inch
DMinimum
200 mm
7.9 inch
A
D
E
F
G
B
C
F
G
2727
