6-49
3. Turn the back cover assembly 3
counterclockwise and remove it.
4. Disconnect the socket 4.
5. Unhook the bulb holder spring 5,
and pull out the bulb 6.
NOTICE
The headlight bulb’s life may be
shortened by oil from your fingers
if you touch it.
When replacing the headlight
bulb, be careful not to touch the
glass. Grasp the new bulb with a
clean cloth.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSX1250FA and is the answer not in the manual?

Suzuki GSX1250FA Specifications

General IconGeneral
Engine Type4-stroke, liquid-cooled, DOHC
Engine Displacement1255 cc
Bore x Stroke79.0 mm x 64.0 mm
Compression Ratio10.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
StarterElectric
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDisc, twin
Rear BrakesDisc
Front Tire Size120/70ZR17M/C (58W), tubeless
Rear Tire Size180/55ZR17M/C (73W), tubeless
Overall Length2130 mm
Overall Width790 mm
Wheelbase1485 mm
Seat Height805 mm
Curb Weight257 kg
Fuel Tank Capacity19.0 L
