Suzuki GSX1250FA User Manual

2-5
KEY
(Canada and Australia)
This motorcycle comes equipped with
a main ignition key and a spare one.
Keep the spare key in a safe place.
IGNITION SWITCH
The ignition switch has 4 positions:
“OFF” POSITION
All electrical circuits are cut off. The
engine will not start. The key can be
removed.
“ON” POSITION
The ignition circuit is completed and
the engine can now be started. The
headlight and taillight will automati-
cally be turned on when the key is in
this position. The key cannot be
removed from the ignition switch in
this position.
NOTE: Start the engine promptly after
turning the key to the “ON” position,
or the battery will lose power due to
consumption by the headlight and tail-
light.
“LOCK” POSITION
To lock the steering, turn the handle-
bar all the way to the left. Push down
and turn the key to the “LOCK” posi-
tion and remove the key. All electrical
circuits are cut off.
O
N
O
F
F
L
O
C
K
P
I
G
N
I
T
I
O
N
P
U
S
H

Suzuki GSX1250FA Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Engine Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire Size	120/70ZR17M/C (58W), tubeless
Rear Tire Size	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Wheelbase	1485 mm
Seat Height	805 mm
Curb Weight	257 kg
Fuel Tank Capacity	19.0 L
