6-7
TOOLS
A tool kit is supplied and located
under the seat.
NOTE: Place the tool bag as follows:
• Center the tool bag on the holder.
• Face the tool flap downward and
at the right.
FUEL TANK REMOVAL
1. Place the motorcycle on the side
stand.
2. Remove the seat. Remove the two
bolts 1.
3. Lift the rear end of the fuel tank
and slide it back.
NOTICE
Lifting up the rear end of the fuel
tank by force can damage the fuel
tank front bracket, fuel hose and
wiring harness.
Do not lift the fuel tank rear end
more than 50 mm.
50 mm

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSX1250FA and is the answer not in the manual?

Suzuki GSX1250FA Specifications

General IconGeneral
Engine Type4-stroke, liquid-cooled, DOHC
Engine Displacement1255 cc
Bore x Stroke79.0 mm x 64.0 mm
Compression Ratio10.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
StarterElectric
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDisc, twin
Rear BrakesDisc
Front Tire Size120/70ZR17M/C (58W), tubeless
Rear Tire Size180/55ZR17M/C (73W), tubeless
Overall Length2130 mm
Overall Width790 mm
Wheelbase1485 mm
Seat Height805 mm
Curb Weight257 kg
Fuel Tank Capacity19.0 L
