Suzuki GSX1250FA User Manual

2-20
ELECTRIC STARTER SWITCH “”
3
This switch is used for operating the
starter motor. With the ignition switch
in the “ON” position, the engine stop
switch in “”, the transmission in
neutral, squeeze the clutch lever,
push the electric starter switch to
operate the starter motor and start
the engine.
NOTE: The headlight will go off when
the electric starter switch is pushed.
NOTE: This motorcycle is equipped
with interlock system for the ignition
circuit and the starter circuit. The
engine can only be started if:
• The transmission is in neutral and
the clutch is disengaged, or
• The transmission is in gear, the
side stand is fully up and the
clutch is disengaged.
THROTTLE GRIP 4
Engine speed is controlled by the
position of the throttle grip. Turn it
toward you to increase engine speed.
Turn it away from you to decrease
engine speed.
NOTICE
Engaging the starter motor for
more than five seconds at a time
can damage the starter motor and
wiring harness from overheating.
Do not engage the starter motor
for more than five seconds at a
time. If the engine does not start
after several attempts, check the
fuel supply and ignition system.
Refer to the TROUBLESHOOTING
section in this manual.

Suzuki GSX1250FA Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Engine Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire Size	120/70ZR17M/C (58W), tubeless
Rear Tire Size	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Wheelbase	1485 mm
Seat Height	805 mm
Curb Weight	257 kg
Fuel Tank Capacity	19.0 L
