4-62 DISASSEMBLY AND ASSEMBLY
• Pour brake fluid up to the UPPER line A.
Specification and classification: DOT 4
• Connect a transparent tube to the bleeder valve and set the
other end into a receptacle.
• Pump the brake lever/pedal until air bubbles stop coming out
from the reservoir.
• Hold the brake lever/pedal in the squeezed position.
• Open the bleeder valve and tighten the bleeder valve.
• Release the brake lever/pedal.
• Repeat this sequence until air bubbles stop coming out from
the bleeder valve.
NOTE:
* Do not release the brake lever/pedal while the bleeder valve is
opened.
* Replenish brake fluid to the UPPER line when the brake fluid
level drops below LOWER line.
• Tighten the air bleeder valve.
Air bleeder valve: 6 N·m (0.6 kgf-m, 4.5 lbf-ft)
• Pour brake fluid up to the UPPER line.
• Reassemble the reservoir cap.
