3-10 MACHINE TUNING
• Check or adjust the clearance between the lock-nut 2 and
center bolt 5 to provide more than 1 mm (0.04 in) and more.
(4-86)
• Tighten the lock-nut/center bolt to the specified torque.
 Lock-nut/center bolt: 22 N·m (2.2 kgf-m, 16.0 lbf-ft)
• Tighten the center bolt to the specified torque.
 Center bolt: 69 N·m (6.9 kgf-m, 50.0 lbf-ft)
b 1 mm (0.04 in) and more
• Pour the specified amount fork oil into the outer tube in accor-
dance with the following table.
 FORK OIL SS-19 or equivalent
SPRING
STD OIL
QUANTITY
OIL QUANTITY
ADJ. RANGE
Soft 51171-28H10
388 ml
(13.11/13.66
US/Imp oz)
319 – 408 ml
(
10.78/11.23 –
13.79/14.37
US/Imp oz)
STD 51171-28H00
388 ml
(13.11/13.66
US/Imp oz)
319 – 408 ml
(
10.78/11.23 –
13.79/14.37
US/Imp oz)
Hard 51171-28H20
388 ml
(13.11/13.66
US/Imp oz)
319 – 408 ml
(
10.78/11.23 –
13.79/14.37
US/Imp oz)
