7-33
INSPECTION AND MAINTENANCE
83RM0-01E
Coolant Replacement
Since special procedures are required, we
recommend you take your vehicle to your
SUZUKI dealer for coolant replacement.
Air Cleaner
If the air cleaner is clogged with dust, there
will be greater intake resistance, resulting
in decreased power output and increased
fuel consumption.
(For M16A engine model)
61MM0B063
1) Remove the air cleaner inlet hose (1).
2) Remove the bolts (2), loosen the bolt
(3) and lift the air cleaner case (4)
directly above.
61MM0B064
3) Unclamp the side clamps, and remove
the element from the air cleaner case. If
it appears to be dirty, replace it with a
new one.
4) Clamp the side clamps or tighten the
bolts securely.
NOTICE
When lifting the air cleaner, make sure
the air cleaner does not interfere the
engine oil dipstick (5) to avoid dam-
age the dipstick.
To Next Page
