Sym HD 200 EVO - When there is an Abnormal Condition or a Trouble; Engine Start Troubleshooting

26
11. When there is an Abnormal Condition or a Trouble
DIAGNOSIS WHEN ENGINE DOES NOT START
(1). Has the ignition switch key been turned to “ON”
position?
(2). Anti-thief switch at〝UNLOCK〞or〝 〞position？
(3). Is there enough fuel in the fuel tank?
(4). Is the rear or front wheel brakes applied when
pressing starting button?
(5). Do you rotate the throttle valve handle while
pressing starting the button?
(6). Turn the ignition switch key “ON”, and press horn
button down, if the horn does not sound, the fuse
may have been blown.
【Have your scooter checked by SYM authorized dealer or franchised dealer immediately if there are no
problems with the above items and engine still can not be started.】
Turn signal
light switch
Horn button
For Front Wheel
For Rear Wheel
