COOLING SYSTEM INSPECTION
(Checking coolant lever)
1. Support vehicle with main stand on a level ground.
2. Check reserved tank from viewing window to see if coolant level is between the upper limit and lower limit
mark.
3. Add coolant up to upper mark if coolant is close to the lower mark.
(Check the cooling system for leakage)
• Check radiator and piping for leakage.
• Check the ground where the vehicle is parked for water dripped from the vehicle.
25
10. Inspection and maintenance before riding
REPLENISHMENT OF COOLANT
Always keep radiator cap tightly closed.
1. Support vehicle on a level ground in a straight
up position.
2. Open the battery cabinet door.
3. Open surge tank cap, refill coolant until reaches
the upper mark.
• If coolant level becomes too low and occurs too
often, it may indicate there is something wrong with
the coolant system.
• To avoid radiator getting rusty, do not use
coolants other than those recommended.
Coolant recommended: SYM Bramax radiator
agent Concentration: 50%
Radiator coolant capacity: 1,400 cc.
