Installation |
7
4.3 Installing the unit
Caution
Make sure that the hatch to the electrical connection box doesn’t fall down during installation in false
ceiling.
The unit can be installed in the positions shown in figure 3.
When the HW units are mounted horizontally on a wall, always make sure that the water pipe connections are above
the battery, so the HW battery can be properly de-aired. By unscrewing four screws the HW battery can easily be
rotated.
Prepare the surface where the unit is to be mounted. Make sure that the surface is flat, levelled and that it carries the
weight of the unit. Perform the installation in accordance with local rules and regulations.
Fig. 3 Mounting of HW units
130324 | A004
