TB8100 Installation Guide 3

Contents

1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.1 Personal Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Equipment Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.3 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.4 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.5 Grounding and Lightning Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.6 Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.7 Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.8 Installing the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2 Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.1 Auxiliary Power Supply Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2 RF Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.3 System Control Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.4 System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.5 Service Kit Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

2.6 12V PA Power Saving Control Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Associated Documentation

MBA-00001-xx TB8100 Specifications Manual.

MBA-00005-xx TB8100 Installation and Operation Manual.

MBA-00010-xx TB8100 Service Kit User’s Manual.

MBA-00011-xx TB8100 Calibration Kit User’s Manual.

MB8100-80-00-806 TB8100 Alarm Center User’s Manual.

MBA-00013-xx TBA0STU/TBA0STP Calibration and Test Unit Operation Manual

MBA-00016-xx TB8100 Service Manual.

The characters xx represent the issue number of the documentation. All available TB8100 product

documentation is provided on the Product CD supplied with the base station. Updates may also

be published on the Tait Technical Support website (http://support.taitworld.com).

Tuning and Configuration

If your TB8100 base station has not been tuned to your requirements at the factory, you will need

to tune the reciter modules before operating them in your radio system. To do this you will need

to use the Calibration Kit software included on the Product CD, plus the Calibration and Test Unit.

The TB8100 base station has been programmed with a default software configuration and default

passwords at the factory. You will need to use the Service Kit software to configure your base station

to suit the requirements of your radio system. Refer to the Calibration Kit and Service Kit

documentation for full details on these procedures.
