Midian Encryption Programming and Service Manual TM8000 Encryption 57
June 2006 © Tait Electronics Limited
4.8 TM8000 Encryption Options PCB Information
IPN XA2343-01-PBA
Parts List
Part IPN Description
C1 016-08100-02 Cap Elec SMD 10M 5.5*5 35v 20% A7 1D6
C2 018-16100-00 Cap 0603 100n 16v x7r + - 10% C3 1B6
C5 018-16100-00 Cap 0603 100n 16v x7r + - 10% D3 1B7
C6 018-16100-00 Cap 0603 100n 16v x7r + - 10% F4 1B8
C7 018-16100-00 Cap 0603 100n 16v x7r + - 10% D4 1B9
C11 018-16100-00 Cap 0603 100n 16v x7r + - 10% C3 1J3
C12 018-16100-00 Cap 0603 100n 16v x7r + - 10% D3 1J4
C13 not fitted in this application F3 1H4
C14 not fitted in this application F3 1H5
C15 not fitted in this application E3 1H4
C16 not fitted in this application E2 1G4
C17 not fitted in this application E2 1H5
C18 not fitted in this application B3 1E4
C19 018-16100-00 Cap 0603 100n 16v x7r + - 10% B3 1E4
C20 018-16100-00 Cap 0603 100n 16v x7r + - 10% B7 1D6
C23 018-16100-00 Cap 0603 100n 16v x7r + - 10% C8 1D7
C24 016-08100-02 Cap Elec SMD 10M 5.5*5 35v 20% C9 1D7
C25 not fitted in this application B1 1A6
C26 not fitted in this application F1 1A6
C27 not fitted in this application B6 1A7
C28 not fitted in this application G5 1A8
C29 not fitted in this application B10 1A8
C30 not fitted in this application G9 1A9
C33 018-16100-00 Cap 0603 100n 16v x7r + - 10% F4 1F8
C34 018-16100-00 Cap 0603 100n 16v x7r + - 10% G4 1F8
C35 018-16100-00 Cap 0603 100n 16v x7r + - 10% B1 1J12
C36 018-16100-00 Cap 0603 100n 16v x7r + - 10% B1 1H13
C37 018-16100-00 Cap 0603 100n 16v x7r + - 10% E5 1G14
C39 not fitted in this application E4 1D10
C40 018-16100-00 Cap 0603 100n 16v x7r + - 10% E3 1D10
C43 not fitted in this application E3 1D11
C44 not fitted in this application D3 1D12
C45 018-16100-00 Cap 0603 100n 16v x7r + - 10% D4 1E12
C46 018-16100-00 Cap 0603 100n 16v x7r + - 10% D3 1D12
C47 not fitted in this application D4 1B12
C48 018-16100-00 Cap 0603 100n 16v x7r + - 10% D4 1B13
C49 018-16100-00 Cap 0603 100n 16v x7r + - 10% D4 1C13
C50 015-27100-08 Cap Cer 0805 X7R 1uF 16V 10% E3 1C14
D1 001-10165-00 DIODE BAT165 sch SOD323 C3 1J2
D2 001-10054-00 DIODE BAT54S B3 1F2
F1 265-10055-00 Fuse SMD 0.3a Rstbl 030-2 B2 1G2
FL1 012-14100-00 Cap Cer SMD 1N Array EMI Supr C1 1J7 1J8 1H10 1J9
FL2 001-11001-85 DIODE Array ESD/EMI 15KV C1 1G11
FL3 001-11001-85 DIODE Array ESD/EMI 15KV D1 1H10
FL4 012-14100-00 Cap Cer SMD 1N Array EMI Supr D1 1J6 1J7 1J8 1J9
