6.3 Batteries do not get charged
6.4 Vacuum motor does not switch on
Part Position
Order
No.
Do/ Perform If Then Else
Charger
input
06/111 4123114
• Connect charger to the
mains
• Measure the input Voltage
Input = Main volt-
age
Check charger
output
Check mains cord/
Exchange mains
cord
Charger
output
06/109 4125935
• Leave charger connected
to batteries
• Measure the voltage at the
output pins of the charger
Charging voltage
available
Check voltage at
batteries
Exchange charger
Table: Troubleshooting - Batteries do not get charged
Part Position Order
No.
Do/ Perform If Then Else
Connec-
tion block
02/143 4082740
• Switch vacuum motor on/
off
• Measure the voltage at the
connection block
Power changes 0/
24V DC
Check carbon
brushes
Exchange vaccum
motor
Exchange control
label
Table 3: Troubleshooting - Vacuum motor does not switch on
