Structural layout
1 Dosage cup
2 Filling level indicator
3 Dirt sieve
4 Recovery tank
5 Shell handle
6 Brush unit
7 Tools (brushes, pads, etc.)
8 Fresh water tank filter
9 Drain opening
10 Drain hose fresh water tank (blue cover)
11 Fresh water tank
12 Operating hour counter (option)
13 Driving handle
14 Operating lever (brush drive)
15 Adjusting lever for driving handle inclination
16 Suction filter
17 Float (Overfill protection recovery tank)
18 Suction hose turbine
19 Cable hook for charger main cord
20 Cleaning solution manual quantity regulation
21 Battery disconnection socket (coding)
22 Foot pedal squeegee
23 Suction hose squeegee
24 Squeegee
25 Foot pedal tool
26 Drain hose recovery tank (red cover)
27 Service display
28 Battery charging level indicator
29 Battery indicator
30 Cleaning solution supply button (ON/OFF)
31 ECO mode button (ON/OFF)
32 Suction unit button (ON/OFF)
33 Main switch button (ON/OFF)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
max.60°C
max.140°F
151617
18
19
21
22 23 24 25
26
27
28
29
30313233
20
