Taylor 702 User Manual

8
Operator Parts Identification
Models 702/741/772
Section 4 Operator Parts Identification
Model 702
Item Description Part No.
1 Cover A.-Hopper X38458
1a Knob-Hopper Cover 025429
2 Tube-Feed-SS-5/32 Hole 028967-2
3 Panel-Rear 047008
4 Panel-Side 702 Right 050928
5 Pan-Drip 13-1/4 Long 039027
6 Panel-Side 5472 HT Upper L & R 042317
7 Shield-Splash 15” L x 5-13/32 022763
Item Description Part No.
8 Tray-Drip 14-7/8 L x 5-1/8 SG 013690
9 Panel A.-Front X50930
10 Stud-Nose Cone 022822
11 Panel A.-Side Left X50940
12 Gasket-Hopper Cover 038375
13 Skirt-Air Flow 049069
14 Leg-4” SS w/out O-Ring 013458

Taylor 702 Specifications

General

Brand	Taylor
Model	702
Category	Freezer
Language	English
