Technics SC-EH580 User Manual

28
RQT6301
Recording operations
D
1
2
3
C
A
A
B
COUNTER
RESET
1
COUNTER
DISPLAY
COUNTER
RESET
DISPLAY
DECK 1/2
6
3
4
2
5
132
< OPEN
DOLBY NR
REV MODE
A
A
2
NR Î
2
NR Î
»A
To display the tape counter while recording
Press [COUNTER DISPLAY].
The counter is displayed for about 5 seconds.
³Press [COUNTER RESET] to reset the counter.
³To display or reset the tape counter for deck 1, first press [DECK 1/2].
»B
Erasing recordings
 Press [INPUT SELECTOR] to select “TAPE”.
Insert the recorded tape into deck 2.
! Press [DOLBY NR] so the “ë NR” indicator goes out.
" Select the reverse mode.
# Press [´ REC PAUSE].
$ Press ["] or [!].
»C
Erasure prevention
The illustration shows how to remove the tabs to prevent recording. To
record on the tape again, cover as shown, being careful not to cover the
high position discrimination hole.
Your attention is drawn to the fact that recording pre-recorded
tapes or discs or other published or broadcast material may infringe
copyright laws.
»
D
Preparatory steps
Do these steps before each recording.
Wind up the leader tape so recording can begin immediately.
1 Press [< OPEN] on deck 2 and insert the
cassette.
2 Press [DOLBY NR] to select Dolby NR on
(“ëNR” appears) or off.
(á “Dolby noise reduction”, page 19)
3 Press [REV MODE] to select the reverse mode.
Each time you press the button:
>: One side only records.
@ and B: Both sides record (forward >reverse).
“B” automatically changes to “@” when [´ REC PAUSE], [EDIT]
or [TAPE EDIT] is pressed.
Before recording (Deck 2 only)
See page 39 for tape selection.
Note
[EH780]
You cannot record when [6CH DISCRETE INPUT] is selected.
Volume, sound quality and surround effects have no effect on re-
cording. Sound quality and surround effects are automatically set to
flat when recording.
Side A
Tab for side B Tab for side A
To re-record
Normal tape High-position tape
Discrimination hole
Forward side
Tape facing down
