Maintenance
English
(25)
Specifications
General
Power supply AC 110 - 240 V, 50/60 Hz
Power
consumption
14 W (Power ON)
0.2 W (Power OFF)
Dimensions
(W×H×D)
453 x 173 x 372 mm
Mass Approx. 18.0 k
g
Turntable section
Type Direct drive manual
turntable
Drive method Direct drive
Motor Brushless DC motor
Turntable Brass and aluminum diecast
combined
Diameter: 332 mm
Mass: Approx. 3.6 k
g
(including a rubber sheet)
Turntable speeds 33-1/3, 45 and 78 rpm
Variable range
pitch
±8 % and ±16 %
Starting torque 3.3 k
g
-cm
Build-up
characteristics
0.7 s. from standstill to
33-1/3 rpm
Braking system Electronic brake
Wow and flutter 0.025 % W.R.M.S.
(JIS C5521)
Rumble 78 dB (IEC 98A weighted)
Tone arm section
Type Static Balance
Effective length 230 mm
Overhang 15 mm
Tracking error
angle
Within 2° 32' (at the outer
groove of 30 cm (12“)
record)
Within 0° 32' (at the inner
groove of 30 cm (12“)
record)
Offset angle 22°
Arm-height
adjustment range
0 – 6 mm
Stylus pressure
adjustment range
0 – 4
g
(direct reading)
Head shell weight Approx. 7.6
g
Applicable
cartridge weight
range
(Without the auxiliary weight)
5.6 to 12.0
g
14.3 to 20.7
g
(including the
head shell)
(With the small auxiliary weight)
10.0 to 16.4
g
18.7 to 25.1
g
(including the
head shell)
(With the big auxiliary weight)
14.3 to 19.8
g
23.0 to 28.5
g
(including the
head shell)
Head shell
terminal lug
1.2 mm
φ
4-pin terminal lug
Specifications are subject to change without
notice.
25
