Technics SL-DZ1200PP User Manual

: Negative voltage signal line
13.2. Schematic Diagram
14. Printed Circuit Board
14.1. CD SERVO P.C.B. test point table
Test point IC Pin No. etc.
TPS 2 Q1 : E
TPS35 IC4 : Pin No.22
TPS44 IC3 : Pin No.36
TPS45 IC3 : Pin No.39
TPS48 IC3 : Pin No.35
TPS101 IC102 : Pin No.3
TPS105 IC102 : Pin
No.44
TPS106 IC102 : Pin
No.45
TPS107 IC102 : Pin
No.46
TPS129 IC102 : Pin
No.71
TPS130 +B
TPS131 GND
V
CC
+B
GND GND
VREF VREF
SL + IC5 : Pin No.10
SL - IC5 : Pin No.11
F + IC5 : Pin No.16
F - IC5 : Pin No.15
T + IC5 : Pin No.14
T - IC5 : Pin No.13
FE IC3 : Pin No.32
TE IC3 : Pin No.33
RF IC1 : Pin No.6
ARF IC3 : Pin No.44
Test point IC Pin No. etc.
TRD IC3 : Pin No.27
FOD IC3 : Pin No.28
IPFLAG IC3 : Pin No.64
43
