Technics SL-DZ1200PP User Manual

Pin
No.
Terminal
Name
I/O Function
62 P01 I DSP sub code block
clock interruption signal
63 P02 O Interruption signal 0 from
Decoder I/F IC
64 P03 O Interruption signal 1 from
Decoder I/F IC
65 P04 I Sound jump detection at
the time of audio playing.
66 P05 - Not used, open
67 V
SS
0 - GND
68 V
DD
1 I Power supply
69 X2 I Oscillator connection for
a main system clock
oscillation
70 X1 O Oscillator connection for
a main system clock
oscillation
71 IC - It is a direct connected to
Vss0 or Vss1.
72 XT2 - Not used, open
73 XT1 - Not used, open
74 V
DD
0 I Power supply
75 AVREF0 I Power supply for A/D
converter
76 P10 I Mechanism control
control sensor detected
signal 1: PS1
77 P11 I Mechanism control
control sensor detected
signal 2: PS2
78 P12 I Mechanism control
control sensor detected
signal 3: PS3
79 P13 I Mechanism control
control sensor detected
signal 4: PS4
80 P14 - Not used, open
18. Replacement Parts List
Note:
- (PAS) indicates in the Remarks columns indicates parts supplied
by PAS (Panasonic Automotive Systems company) .
72
