25
AGC Performance AGC range: Wider than 80dB
Threshold : 12μV
RF GAIN
20dB
Antenna Attenuation
Three levels: 0dB，-10dB，-20dB
Internal Antennal
1200mm telescoping whip (for use on FM, AIR, SW and SSB
bands)
lFerrite rod antenna φ10X120mm(HQ) (for use from 100kHz
through 1800kHz)
External Antenna
Input
FM
SW
50Ω (BNC type)
AIR
50Ω (BNC type), 500Ω
IF: 455kHz
Signals output greater than 60mV when input greater than 3μV
IF Output
Line Audio Outputs Stereo left and right 300Mv, 4.7kΩ for each output.
Earphone Jack
φ3.5mm, 8~32Ω, stereo type
Internal Speaker 8Ω / 2W, φ100mm
Power supply
DC 6V / 500mA, negative polarity
Outside diameter: φ5.5mm，Core diameter: φ2mm
DC Jack
Batteries : D size, UM1 (alkaline) x 4
AC ~220V/50Hz (AC power cord included for Asia market)
Rated Current 350mA
(Output 650mW, Distortion less than 1%)
Maximum Current less than 500mA
(Output 1500mW)
Current Consumption
Quiescent Current
Standby Current less than 85uA
FM less than 70mA
MW less than 80mA
SW less than 90mA
SSB less than 95mA
Dynamic Current
o o
-5 C to +50 C
Operating
Temperature
Size
Weight
2.7kg (batteries NOT included)
372 (W) X 183 (H) X 153 (D) mm (front handle included)
(DC adaptor included for Europe market)
