Selectivity
FM Stereo crosstalk
IF Frequency
24
SPECIFICATIONS
Frequency range
LW
MW
SW
AIR
FM
100-519kHz
522-1620kHz ----------------- system code "09"
520-1710 kHz (America) -- system code "10"
1711-29999kHz
118-137MHz
87-108MHz
76-108MHz (Japan)
87.5-108MHz (America)
Sensitivity
LW (S/N=26dB)
MW (S/N=26dB)
SW (S/N=26dB)
SSB (S/N=10dB)
AIR (S/N=10dB)
FM (S/N=30dB)
Less than 3mV/m
Less than 0.35mV/m
Less than 18μV
Less than 1μV
Less than 5μV
Less than 3μV
AM
Wideband ±10kHz, Greater than 40dB
Narrowband ±5kHz, Greater than 60dB
Better than 30dB
Signal to Noise Ratio
MW
SW
FM
Greater than 45dB
Greater than 50dB
Greater than 60dB
SSB, AM: 1st IF : 55.845MHz
2nd IF: 455kHz
FM: 1st IF: 10.7MHz (Single Conversion)
Image Rejection
MW/LW/SW
AIR
FM
55.845MHz： Greater than 90dB
455kHz： Greater than 80dB
Greater than 90dB
Greater than 60dB
IF Rejection
AM
FM
55.845MHz： Greater than 60dB
455kHz： Greater than 60dB
10.7MHz： Greater than 100dB
